Wire coatings: The wires in MC cables are either THNN - which are thermoplastic, high-heat and nylon-jacketed - or THWN-2 wires - which are thermoplastic, high-heat and water-resistant.Of the conductors, one is a hot conductor and the other is a neutral conductor. An MC cable may contain more than one hot conductor. Wires: MC cables contain three wires minimum - two are conductor wires and one is a ground wire.Typically consisting of aluminum, this cable sheath covers the wires in an interlocking configuration to allow for flexibility and coverage.
Sheathing: This cable type is defined by the metal sheathing surrounding the insulated wires.Some of the unique features of MC cable include: It is still commonly used today in residential, commercial and industrial building construction. Also called metallic sheathed cable, armored cable (AC) or BX cable, MC cable was one of the first cable types developed for both commercial and residential applications. MC cable was originally developed in the early 1900s by Edwin Greenfield. The most popular MC cables today feature aluminum interlocked armor. MC cable is defined as an assembly of one or more insulated circuits, often enclosed with an armor of metal tape or a metallic sheath. MC is short for “metal-clad,” and this type of cable is sheathed with a metallic coating. Learn what these types of cables are, their differences and when to use MC versus Romex cabling in an installation below.
